SPECIFICATIONS
| Brand: |
Gigabyte |
| Model: |
Aorus B560M Elite |
| Type: |
mATX |
| BIOS Type: | UEFI AMI |
| BIOS Memory Size: | 256 Mbit |
| ACPI Version: | 5.0 |
| Clear CMOS Jumper: | Yes |
| Desktop Management Interface (DMI) Version: | 2.7 |
| System Management BIOS (SMBIOS) Version: | 2.7 |
| Processor Manufacturer: | Intel |
| Processor Socket: | LGA 1200 |
| Compatible Processors: |
Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
|
| Supported Processor Slots: | LGA 1200 (Socket H5) |
| Supported Memory: | DDR4 SDRAM |
| Number Of Memory Slots: | 4 |
| Memory Type: | DIMM |
| Memory Channels: | Dual channel |
| ECC: | Yes |
| Without ECC: | Yes |
| Supported Memory Speed: | 2133,2400,2666,2933,3000,3200MHz |
| RAM Memory Maximum: | 128GB |
| Unbuffered Memory: | Yes |
| Supported Storage Drives: | HDD & SSD |
| Supported Storage Drive Interfaces: | M.2,SATA III |
| Number Of Supported Storage Drives: | 8th |
| Parallel Processing Technology: | 2-Way CrossFireX,Quad GPU CrossFireX |
| Maximum Resolution: | 4096×2304 pixels |
| HDCP: | Yes |
| Number Of USB 2.0 Interfaces: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Ports: | 2 |
| SATA III Connectors: | 6 |
| Front Panel Audio Connector: | Yes |
| Front Panel Connector: | Yes |
| ATX Power Connector (24-pin): | Yes |
| CPU Fan Connector: | Yes |
| Number Of Chassis Fan Plugs: | 3 |
| EPS Power Connector (8-pin): | Yes |
| TPM Connector: | Yes |
| Serial Port Headers: | 1 |
| 12V Power Connection: | Yes |
| Thunderbolt Headers: | 2 |
| RGB LED Header: | Yes |
| Number Of USB 2.0 Ports: | 6 |
| Number Of USB 3.2 Gen 1 (3.1 Gen 1) Type-A Ports: | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type A Slots Count: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C Slots Count: | 1 |
| Number Of Ethernet LAN Ports (RJ-45): | 1 |
| Number Of PS/2 Connections: | 1 |
| Number Of HDMI Ports: | 1 |
| HDMI Version: | 1.4 |
| Number Of DisplayPort Connections: | 1 |
| DisplayPorts Version: | 1.2 |
| Headphone Outputs: | 6 |
| Microphone Input: | Yes |
| USB Plug: | USB Type-A, USB Type-C |
| Built-in Ethernet Port: | Yes |
| Ethernet Interfaces Type: | 2.5 Gigabit Ethernet |
| Wireless Internet Access: | No |
| Motherboard Form Factor: | micro ATX |
| Motherboard Chipset Family: | Intel |
| Motherboard Chipset: | Intel B560 Express |
| Audio Channels: | 7.1 Channels |
| PC Health Monitoring: | Fan, Temperature, Voltage |
| Supports Windows Operating Systems: | Windows 10 x64 |
| PCI Express x1 Slots: | 1 |
| PCI Express x16 Slots: | 2 |
| Number Of M.2 (M) Slots: | 2 |
| Dimensions( B x D): | 244 x 244mm |
| Warranty: | 2 years |
