SPECIFICATIONS
Standards | Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz |
---|---|
WiFi Speeds | AC1900 5 GHz: 1300 Mbps (802.11ac) 2.4 GHz: 600 Mbps (802.11n) |
WiFi Range | 1-2 Bedroom Houses (1-pack)
TP-Link Mesh Technology 3× Antennas (Internal) Beamforming |
WiFi Capacity | Medium
Dual-Band MU-MIMO |
Working Modes | Router Mode Access Point Mode |
SECURITY | |
---|---|
Network Security | SPI Firewall Access Control |
Guest Network | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
WiFi Encryption | WPA-Personal WPA2-Personal |
HARDWARE | |
---|---|
Ethernet Ports | 3× Gigabit Ports
*Per Deco Unit |
Buttons | Reset Button |
SOFTWARE | |
---|---|
Protocol | IPv4 IPv6 |
Parental Controls | URL Filtering Time Controls |
WAN Type | Dynamic IP Static IP PPPoE PPTP L2TP |
Quality of Service | QoS by Device |
Cloud Service | OTA Firmware Upgrade TP-Link ID DDNS |
NAT Forwarding | Port Forwarding UPnP |
IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP | Address Reservation DHCP Client List Server |
DDNS | TP-Link |
Management | Deco App |
TEST DATA | |
---|---|
WiFi Transmission Power | CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) |
PHYSICAL | |
---|---|
Dimensions (W×D×H) | 6.4 × 3.6 × 3.6 in (162.3 × 90.7 × 90.7 mm) |
Package Contents | Deco S7 (3-pack) 3 Deco S7 Units 1 RJ45 Ethernet Cable 3 Power Adapters Quick Installation GuideDeco S7 (2-pack) 2 Deco S7 Units 1 RJ45 Ethernet Cable 2 Power Adapters Quick Installation Guide Deco S7 (1-pack) |
OTHERS | |
---|---|
Certification | CE, FCC, RoHS, NCC, BSMI, JRF, JPA, VCCI |
System Requirements | Android 5.0 or later iOS 9.0 or later *Note: The minimum system requirements will be updated alongside updates to the app, subject to official website information. |
Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~60℃ (-40℉ ~140℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
