SPECIFICATIONS
Brand: | ASRock |
Model: | B560-M Steel Legend |
Type: | mATX |
Processor Manufacturer: | Intel |
Processor Socket: | LGA 1200 |
Compatible Processors: | Intel® Celeron®, Intel Core i5, Intel Core i7, Intel Core i9, Intel® Pentium® |
BIOS Type: | UEFI AMI |
ACPI Version: | 6.0 |
System Management BIOS (SMBIOS) Version: | 2.7 |
Maximum Number Of SMP Processors: | 1 |
Supported Memory: | DDR4 SDRAM |
Number Of Memory Slots: | 4 |
Memory Type: | DIMM |
Memory Channels: | Dual Channel |
Without ECC: | Yes |
Supported Memory Speed: | 4666.4800MHz |
RAM Memory Maximum: | 128GB |
Unbuffered Memory: | Yes |
Supported Storage Drive Interfaces: | M.2,SATA |
Number Of USB 2.0 Interfaces: | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Ports: | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Ports: | 1 |
SATA III Connectors: | 6 |
Front Panel Audio Connector: | Yes |
ATX Power Connector (24-pin): | Yes |
CPU Fan Connector: | Yes |
EPS Power Connector (8-pin): | Yes |
TPM Connector: | Yes |
RGB LED Header: | Yes |
Number Of USB 2.0 Ports: | 1 |
Number of PS/2 Connections: | 1 |
Number Of HDMI Ports: | 1 |
Number Of DisplayPort Connections: | 1 |
DisplayPorts Version: | 1.4 |
S/PDIF Output: | Yes |
Built-in Ethernet Port: | Yes |
Ethernet Interfaces Type: | 2.5 Gigabit Ethernet |
LAN Controller: | Dragon RTL8125BG |
Wake On LAN Ready: | Yes |
Wireless Internet Access: | No |
Component For: | Personal Computer |
Motherboard Chipset: | Intel B560 |
Audio Channels: | 7.1 Channels |
PCI Express x1 (Gen 3.x) Connectors: | 2 |
PCI Express x16 Slots (Gen 4.x): | 1 |
Dimensions (B x D): | 244 X 244mm |
Warranty: | 2 year |
