| Device Type |
Wireless router – 4-port switch (integrated) |
| Enclosure Type |
Desktop |
| Connectivity Technology |
Wireless, wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Frequency Band |
2.4 GHz / 5 GHz |
| Performance |
Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 2402 Mbps |
| Capacity |
Streams: 4 |
| Network / Transport Protocol |
PPTP, L2TP, PPPoE, DHCP, DDNS, IPv4, IPv6 |
| Routing Protocol |
IGMP, static IP routing |
| Remote Management Protocol |
DHCP |
| Encryption Algorithm |
WPA, WPA2, WPA2-Enterprise, WPA3, WPA3-Personal, WPA2-Personal |
| Wi-Fi Rating |
AX3000 |
| Features |
IGMP snooping, parental control, Access Point operational mode, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, port forwarding, reset button, port triggering, dynamic IP mode, IP-MAC binding, DHCP client, tagged VLAN, IGMP proxy, MU-MIMO technology, beamforming technology, Dynamic Frequency Selection (DFS), Airtime Fairness, DMZ support, black list, white list, DynDNS, bridge mode, PPTP server, OpenVPN server, WPS button, IPv6 addressing, IPv4 addressing, Guest Network, Address Reservation, Wi-Fi on/off button |
| Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6, FCC, RoHS |
| Line Properties |
Line Properties |
| Line Coding Format |
OFDMA |
| Expansion / Connectivity |
Expansion / Connectivity |
| Interfaces |
LAN: 4 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 |
| Aerial |
Aerial |
| Aerial |
External |
| Antenna Qty |
4 |
| Power |
Power |
| Power Device |
External power adapter |
| Miscellaneous |
Miscellaneous |
| Cables Included |
1 x network cable |
| Dimensions & Weight |
Dimensions & Weight |
| Width |
26.02 cm |
| Depth |
13.5 cm |
| Height |
4.16 cm |
| Manufacturer Warranty |
Manufacturer Warranty |
| Service & Support |
Limited warranty – 4 Years |
| Environmental Parameters |
Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
10 – 90% (non-condensing) |
