SPECIFICATIONS
| Brand: | Edimax |
| Model: | GS-1026 V2 |
| Ports: | 24 RJ-45 10/100/1000Base-T ports / 2 SFP slots |
| Transmission Method: | Store and forward |
| Transmission Media: | 10BaseT Cat. 3, 4, 5 UTP/STP / 100BaseTX Cat. 5 UTP/STP /1000BaseT Cat. 5e UTP/STP |
| Buttons: | Reset button |
| LED Indicators: | Per port: Link/Act / Per unit: Power |
| Power Input: | 100-240V AC, 50-60 Hz |
| Power Consumption: | 24W (Max) |
| Dimensions (LxWxH): | 441 × 131 × 44 mm |
| Weight: | 1.96kg |
| Switching Capacity: | 48Gbps |
| MAC Address: | 8K |
| Buffer Memory: | 512KB |
| Jumbo Frames (Bytes): | 9K |
| Filtering/Forwarding Rates: | 1000Mbps port – 1,488,000pps / 100Mbps port – 148,800pps / 10Mbps port – 14,880pps |
| Temperature: | Operating: 0 ~ 40℃ / Storage: -40 ~ 70℃ |
| Humidity (Non-condensing): | Operating: 10 ~ 90% / Storage: 5 ~ 90% |
| Standards: | IEEE 802.3 10BaseT Ethernet / IEEE 802.3u 100BaseTX Fast Ethernet / IEEE 802.3ab 1000BaseT Gigabit Ethernet / IEEE 802.3z 1000BaseSX/LX / IEEE 802.3x Full-duplex and flow control /IEEE 802.3az Energy efficient Ethernet |
| Certifications: | FCC Class A, CE |
| Package Contents: | GS-1026 V2 Switch / Quick Installation Guide / Power Cord /Rubber Feet / Rack-Mount Kits |
| Warranty: | 2 years |
