SPECIFICATIONS
Processor: Intel® Core™ i5-13420H, 8C (4P + 4E) / 12T, P-core 2.1 / 4.6GHz, E-core 1.5 / 3.4GHz, 12MB
Graphics: Integrated Intel® UHD Graphics
Chipset : Intel® SoC Platform
Memory: 1x 16GB SO-DIMM DDR4-3200
Memory Slots: Two DDR4 SO-DIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR4-3200
Storage : 512GB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0
Storage Support: Up to two drives, 1x 2.5″ HDD + 1x M.2 SSD
- 2.5″ HDD up to 1TB
- M.2 SSD up to 1TB
Card Reader: No card reader
Optical: None
Audio Chip: High Definition (HD) Audio, Realtek® ALC256 codec
Speakers: 2Wx1
Microphone: No microphone
Power Supply: 65W 89% Adapter
Keyboard: USB Calliope Keyboard, Black, English (UK)
Mouse: USB Calliope Mouse, Black
Optional Bay: 2.5″ HDD Bracket
Expansion Slots: Two M.2 slots (one for WLAN, one for SSD)
Case Color: Black
Stand: None
Adapter Cage: None
Toolless Chassis Screw
Toolless Chassis Screw
Mounting: 1x VESA Mount
Form Factor: Tiny (1L)
Dimensions (WxDxH): 179 x 182.9 x 36.5 mm (7.05 x 7.2 x 1.44 inches)
Weight: Around 1.11 kg (2.45 lbs)
CONNECTIVITY: Ethernet Integrated 100/1000M
WLAN + Bluetooth: Intel® Wi-Fi® 6 AX201, 11ax 2×2 + BT5.1
Front Ports: 1x USB-C® 3.2 Gen 2 (support data transfer and 5V@0.9A charging)
1x USB 3.2 Gen 2 (Always On and 5V@2.1A charging)
1x headphone / microphone combo jack (3.5mm)
Optional Front Ports (configured): None
Rear Ports: 2x USB 2.0
2x USB 3.2 Gen 2
1x HDMI® 2.1 TMDS
1x DisplayPort™ 1.4
1x Ethernet (RJ-45)
Optional Rear Ports (configured): None
Monitor Cable: None
SECURITY & PRIVACY: Security Chip
Firmware TPM 2.0 integrated in SoC: Physical Locks
Kensington® Security Slot™, 3 x 7 mm
Chassis Intrusion Switch
Chassis Intrusion Switch
MANAGEABILITY
System Management
Non-vPro®: SERVICE
Warranty: 3 Years
CERTIFICATIONS: Green Certifications ErP Lot 3 and Lot 7 RoHS compliant
TCO Certified 9.0
SOFTWARE
Operating System: None
Bundled Software: None
