SPECIFICATIONS
| Processor |
Intel® Core™ i7-13700H, 14C (6P + 8E) / 20T, P-core 2.4 / 5.0GHz, E-core 1.8 / 3.7GHz, 24MB
|
| Graphics |
Integrated Intel® Iris® Xe Graphics Functions as UHD Graphics
|
| Chipset |
Intel® SoC Platform
|
| Memory |
1x 16GB SO-DIMM DDR5-5200
|
| Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable
|
| Max Memory |
Up to 64GB DDR5-5200
|
| Storage |
512GB SSD M.2 2242 PCIe® 4.0×4 NVMe®
|
| Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 2TB
|
| Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots
|
| Card Reader |
SD Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby® Audio™
|
| Camera |
FHD 1080p + IR Hybrid with Privacy Shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 71Wh
|
| Power Adapter |
100W USB-C® Slim (3-pin)
|
| Special Features |
Modern Standby
|
| DESIGN | |
| Display |
16″ WUXGA (1920×1200) IPS 300nits Anti-glare, 45% NTSC
|
| Touchscreen |
None
|
| Keyboard |
Backlit, English (UK)
|
| Touchpad |
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
|
| Case Color |
Arctic Grey
|
| Surface Treatment |
Anodizing Sandblasting
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| Dimensions (WxDxH) |
356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches)
|
| Weight |
Starting at 1.7 kg (3.75 lbs)
|
| SOFTWARE | |
| Operating System |
None
|
| Bundled Software |
None
|
| CONNECTIVITY | |
| Ethernet |
100/1000M (RJ-45)
|
| WLAN + Bluetooth |
Wi-Fi® 6, 11ax 2×2 + BT5.2
|
| Standard Ports |
|
| Docking |
Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkBook 16 G6 IRL
|
| Security Chip |
Firmware TPM 2.0 Enabled
|
| Fingerprint Reader |
Touch Style, Integrated in Power Button
|
| Physical Locks |
Kensington® Nano Security Slot™, 2.5 x 6 mm
|
| Other Security |
|
