SPECIFICATIONS
| Brand: |
Corsair |
| Model: |
CV650 |
| Type: |
Power Supply |
| Overall Performance: | 650 W |
| AC Input Voltage: | 100-240V |
| AC Input Frequency: | 47-63 Hz |
| Input Current: | 10 – 5 A |
| Combined Current (+ 3.3V): | 130 W |
| Combined Electricity (+ 12V): | 624 W |
| Combined Current (+ 5V): | 130 W |
| Combined Current (-12V): | 3.6 W |
| Combined Current (+ 5Vsb): | 15 W |
| Max. Output Current (+ 3.3V): | 24 A |
| Max. Output Current (+ 12V): | 52 A |
| Max Output Current (+ 5V): | 20 A |
| Max. Output Current (-12V): | 0.3 A |
| Max. Output Current (+ 5Vsb): | 3 A |
| Motherboard Connector: | 24-pin ATX |
| Power Cable Length Motherboard: | 55 cm |
| Number Of PATA Power Connections: | 2 |
| Number Of SATA Power Connectors: | 6th |
| SATA Power Cord Length: | 690 mm |
| EPS Power Connection (4 + 4-pin): | Yes |
| Number Of PCI Express Power Connectors 6 + 2pin: | 2 |
| PCI Express Power Cord Length: | 67 cm |
| 80 Plus Certification: | 80 PLUS Bronze |
| Product Colour: | Black |
| Cooling: | Active |
| Fan Diameter: | 12 cm |
| Warranty: | 2 Years |
